Laser Scribing Electrical Steel
BRAND: PROMISTEEL
THICKNESS:0.2~0.3mm
WIDTH: 650mm-1200mm
CORE LOSS: 70/80/85 P1.7/50 W/kg
PAYMENT: T/T, L/C, etc
APPLICATION: transformer
MOQ: 25tons
SUPPLY CAPABILITY:10000 tons/month
specification
China Laser scribing electrical steel manufacturer and supplier, we provide Laser scribing electrical steel to overseas buyers at the most competitive price with good quality and on-time delivery.
Thickness: 0.2~0.3mm
Width: 650~1200mm, or customized
Packing: Standard export package
Application: Large motor,Transformer,Electromagnetic device,Reactor,Large transformer,Small transformer,Distribution transformer......
R |
RK | thickness | core loss（w/kg） | max core loss （w/kg） | |||
| R.rM | P.g | P.g | P.w | P | |||
| 20R060 20R065 20R070 20R075 20R080 20R085 |
20RK060 20RK065 20RK070 20RK075 20RK080 20RK085 |
0.20mm | 0.60 0.65 0.70 0.75 0.80 0.85 |
0.60 0.65 0.69 0.74 0.78 0.82 |
0.77 0.83 0.88 0.95 1.00 1.05 |
0.45 0.48 0.51 0.54 0.56 0.60 |
0.60 0.64 0.67 0.7] 0.74 0.80 |
| 23R070 23R075 23R080 23R085 23R090 |
23RK070 23RK075 23RK080 23RK085 23RK090 |
0.23mm | 0.70 0.75 0.80 0.85 0.90 |
0.70 0.75 0.79 0.82 0.88 |
0.93 0.99 1.04 1.08 1.15 |
0.54 0.56 0.59 0.61 0.65 |
0.71 0.74 0.78 0.81 0.85 |
| 27R080 27R085 27R090 27R095 |
27RK080 27RK085 27RK090 27RK095 |
0.21mm | 0.80 0.85 0.90 0.95 |
0.80 0.84 0.87 0.92 |
1.06 1.11 1.15 1.22 |
0.61 0.64 0.66 0.69 |
0.8] 0.84 0.87 0.91 |
| 30R090 30R095 30R100 30R105 |
30RK090 30RK095 30RK100 30KK105 |
0.30mm | 0.90 0.95 1.00 1.05 |
0.89 0.92 0.96 1.00 |
1.18 1.22 1.26 1.32 |
0.68 0.71 0.73 0.76 |
0.9 0.94 0.98 1.01 |
The table above shows the widest range of product dimensions. For a detailed acceptable order range, please contact Sales & Marketing Division.
Quality
Packaging & Container Loading
1. 0ne pass of pet
2. Inner and outer plastic corner guards
3. The inner and outer silicon steel special antirust papershall be fully sealed
4. Plastic film full seal
5. Corrugated paper inner and outer guard board
6. Inner and outer corner guards
7. Exquisite wooden support
Applications
Grain-oriented silicon steel is a special type of silicon steel whose grains are oriented in a specific direction to improve its magnetic permeability and magnetic properties. This characteristic makes grain-oriented silicon steel have advantages in some specific application fields. The following are some of the main application areas of grain oriented silicon steel:
Transformer core: Grain oriented silicon steel is widely used to manufacture the core of large transformers. Its high magnetic permeability and low iron loss characteristics make the transformer more efficient, reducing energy consumption and improving energy transfer efficiency.
Motor: Using oriented silicon steel in the motor can reduce hysteresis loss and iron loss, and improve the efficiency and performance of the motor.
Generators: Grain-oriented silicon steel is suitable for various types of generators, including wind, hydro and gas generators. It can improve the energy efficiency and stability of the generator.
Electromagnetic coils: In the manufacture of electromagnetic coils and transformer coils, grain-oriented silicon steel can reduce energy loss and improve the performance of coils, so it can be used in electronic and electrical equipment.
Magnetic sensors: Oriented silicon steel is very useful in the manufacture of highly sensitive magnetic sensors, such as those used for magnetic field detection and positioning.
Power transmission and distribution equipment: Similar to ordinary silicon steel, oriented silicon steel is also used to manufacture power transmission and distribution equipment, such as transmission line towers and substation equipment.
Electronic transformers: In some high-performance electronic transformers, grain-oriented silicon steel can be used to improve energy transmission efficiency and performance.
Hot Tags: laser scribing electrical steel, China laser scribing electrical steel manufacturers, suppliers, Oriented Silicon Steel, M36 Silicon Steel Coil, CRGO Steel
